The MSI MAG Z790 TOMAHAWK WiFi motherboard provides a solid foundation for a high-performance Intel build, supporting the latest DDR5 memory and PCIe 5.0 connectivity. Designed for LGA 1700 processors and the Intel Z790 chipset, this ATX board combines fast storage, robust power delivery, and integrated Wi-Fi 6E, making it ideal for gaming, content creation, or workstations. It features 4 DDR5 slots up to 7200MHz, a PCIe 5.0 x16 slot for new graphics cards, and multiple M.2 slots with heatsinks to keep NVMe drives cool under load.
Connectivity includes Intel 2.5Gbps LAN, Wi-Fi 6E, Bluetooth v5.2, and a rear I-O with 5 USB 3.1 ports, 2 USB Type-C ports, HDMI and DisplayPort outputs, plus Ethernet. Storage offers 3 M.2 PCIe Gen 4.0 x4 slots, 1 M.2 slot supporting PCIe Gen 4.0 x4 and SATA, and 7 SATA 6Gb-s connectors for expansion. The board has an extended heatsink with M.2 Shield Frozr cooling, AUDIO BOOST 5 for clear sound, and rear panel buttons for power, Q-Flash Plus, and Clear CMOS. Measuring 304.8mm by 243.84mm, it fits standard ATX cases and includes a 3-year manufacturer's guarantee.
General features:
- Enhanced Power Design, Supports DDR5, Lightning-Fast Experience.
- ATX form factor.
- Intel Z790.
- Memory slots:4.
- Memory standard: DDR5.
- Expansion slots:1 x PCIe 5.0 x16, 1 x PCIe 4.0 x16, 1 x PCIe 3.0 x1.
- Storage slots:3 x M.2 PCIe Gen 4.0 x4, 1 x M.2 PCIe Gen 4.0 x4/SATA, 7 x S-ATA 6Gb/s.
- Power button.
- Q-flash plus button.
- Clear CMOS button.
Cooling:
- Extended Heatsink Design, M.2 Shield Frozr.
- Heatsink.
- M.2 heatsinks.
Connectivity:
- Wi-Fi 6E, Bluetooth v5.2, Intel 2.5Gbps LAN.
- 5 USB 3.1 ports.
- 2 USB type C ports.
- 1 Ethernet port.
- 1 HDMI ports.
- 1 Display port.
- Headphones jack.
General information:
- Weight 1880g.
- Size H70, W243.84, D304.8 mm.
- Manufacturer's 3 year guarantee.
- Supports SATA-II hard drive.
- Supports 7200MHz memory.
- EAN: 4711377025492.
